Feature
Absorbtion for large amount of thermal expansion:
Double Bellows Expansion Joints are employed in piping systems to absorb
large amount of dierential thermal expansion while and lateral displacment
containing the system pressure.
Maximize the productivity:
Standard design of movement and material maximizes the productivity while
the custom design maximizes the suitability for special applications.
Reliability:
Computer designed bellows element complies with EJMA criteria.
Quality:
All products are tested before delivery according to relevant code or ISO
quality control system.
![](/up/image/SJT7200series/%E7%89%B9%E9%95%B7(%E8%A1%A8).jpg)
![](/up/image/SJT7200series/%E6%A7%8B%E9%80%A0.jpg)
![](/up/image/SJT7200series/%E5%AF%B8%E6%B3%95%E8%A1%A8.jpg)
Nuts are xed by welding for allowable movement setting
Shipping devices (painted yellow) must be removed prior to start-up or testing the system.
Please consult us for other material, pressure, temperature and movement designs.
Please read the instruction xxxxx before designing and installation.
